MILLIMETER-WAVE EMCZN30706A
Millimeter-Wave Pyramidal Horn Measurement Antenna
Millimeter-Wave Pyramidal Horn Measurement Antenna with published frequency coverage of 50 GHz–70 GHz. It is intended for millimeter-wave emissions and immunity testing and integration into complete EMC test chains.
MIL-STD-461H
50 GHz–70 GHzFrequency coverage
50 GHz–70 GHzFrequency range
UG385/UWaveguide flange
PRODUCT CAPABILITY
Designed around the measurement.
Designed for millimeter-wave antennas applications
Operating coverage: 50 GHz–70 GHz
Supports integration into complete EMC measurement and test chains
Technical configuration is matched to the applicable method, interfaces and required accessories
KEY SPECIFICATIONS
At a glance.
Key published specifications for initial equipment selection. Final configuration, accessories and calibration scope are confirmed in the datasheet and quotation.
Frequency range50 GHz–70 GHz
Waveguide flangeUG385/U
Maximum power≤ 20 W
GainApprox. 24.06–25.68 dBi
Need the complete technical data?Download the English datasheet.
Building a complete test chain?Share the standard, level and test object.
Contact ZHINAN CONFIGURATION CHECKLIST
Make the quotation technically complete.
These are the points our application team will confirm before finalizing the model, accessories and calibration scope.
Mechanical setup
Plan the mast or tripod, adapters, cable routing and required orientation.
Calibration package
Confirm antenna-factor, gain or VSWR data and the required calibration scope.
PRODUCT QUESTIONS
What engineers ask before selection.
A concise starting point for evaluating ZN30706A. The final model, accessories and calibration scope are confirmed against the complete test requirement.
What is the ZN30706A used for?
ZN30706A is designed for Millimeter-wave EMC, High-frequency emissions, High-frequency immunity. Its published frequency coverage is 50 GHz–70 GHz.
What frequency range does the ZN30706A cover?
The published frequency coverage is 50 GHz–70 GHz. Final usable coverage depends on the complete measurement chain, interfaces, accessories and the applicable test method.
Which standards are associated with the ZN30706A?
This product is associated with MIL-STD-461H on the ZHINAN product page. The exact edition, test setup and applicability should be confirmed for the customer project.
What information is needed to configure or quote the ZN30706A?
Please provide the applicable standard, required frequency range and level, test object, existing equipment interfaces, accessories and calibration or documentation requirements.
