EMC TEST ANTENNASZN30505A
Biconical Antenna
Biconical Antenna for test antennas applications across 30 MHz-300 MHz, designed for integration into laboratory and field EMC measurement chains.
CISPR 16 seriesMIL-STD-461H
30 MHz-300 MHzFrequency coverage
30 MHz-300 MHzFrequency range
50 ΩImpedance
PRODUCT CAPABILITY
Designed around the measurement.
Designed for test antennas applications
Operating coverage: 30 MHz-300 MHz
Supports integration into complete EMC measurement and test chains
Technical configuration is matched to the applicable method, interfaces and required accessories
KEY SPECIFICATIONS
At a glance.
Key published specifications for initial equipment selection. Final configuration, accessories and calibration scope are confirmed in the datasheet and quotation.
Frequency range30 MHz-300 MHz
Impedance50 Ω
Average VSWR< 4
WeightApprox. 3.5 kg
Need the complete technical data?Download the English datasheet.
Building a complete test chain?Share the standard, level and test object.
