EMC TEST ANTENNASZN30603
Vehicle Transmitter-Simulation Antenna Set
An antenna set covering 1.8 MHz-6 GHz for vehicle transmitter-simulation immunity tests. It supports configurations representing narrowband sources such as vehicle radios, mobile communications, two-way radios, Bluetooth, WLAN and 5G NR.
ISO 11452 series
1.8 MHz–6 GHzFrequency coverage
1.8 MHz-6 GHzFrequency range
HF / VHF / UHF / TETRA / GSM / LTE / WLAN / 5G NRTypical bands
PRODUCT CAPABILITY
Designed around the measurement.
Frequency range: 1.8 MHz-6 GHz
Typical bands: HF / VHF / UHF / TETRA / GSM / LTE / WLAN / 5G NR
Typical configuration: Multiple rod antennas for separate frequency bands
Supporting equipment: Signal generator, power amplifier, power meter and directional coupler
KEY SPECIFICATIONS
At a glance.
Key published specifications for initial equipment selection. Final configuration, accessories and calibration scope are confirmed in the datasheet and quotation.
Frequency range1.8 MHz-6 GHz
Typical bandsHF / VHF / UHF / TETRA / GSM / LTE / WLAN / 5G NR
Typical configurationMultiple rod antennas for separate frequency bands
Supporting equipmentSignal generator, power amplifier, power meter and directional coupler
Test applicationVehicle transmitter-simulation testing
Need the complete technical data?Download the English datasheet.
Building a complete test chain?Share the standard, level and test object.
Contact ZHINAN CONFIGURATION CHECKLIST
Make the quotation technically complete.
These are the points our application team will confirm before finalizing the model, accessories and calibration scope.
Mechanical setup
Plan the mast or tripod, adapters, cable routing and required orientation.
Calibration package
Confirm antenna-factor, gain or VSWR data and the required calibration scope.
PRODUCT QUESTIONS
What engineers ask before selection.
A concise starting point for evaluating ZN30603. The final model, accessories and calibration scope are confirmed against the complete test requirement.
What is the ZN30603 used for?
ZN30603 is designed for Radiated emissions, Radiated immunity, Field calibration. Its published frequency coverage is 1.8 MHz–6 GHz.
What frequency range does the ZN30603 cover?
The published frequency coverage is 1.8 MHz–6 GHz. Final usable coverage depends on the complete measurement chain, interfaces, accessories and the applicable test method.
Which standards are associated with the ZN30603?
This product is associated with ISO 11452 series on the ZHINAN product page. The exact edition, test setup and applicability should be confirmed for the customer project.
What information is needed to configure or quote the ZN30603?
Please provide the applicable standard, required frequency range and level, test object, existing equipment interfaces, accessories and calibration or documentation requirements.
