SHIELDING TEST SYSTEMSZN1690B
Low-Frequency Large-Loop Shielding Test System
Low-Frequency Large-Loop Shielding Test System for shielding effectiveness applications across 106 kHz, designed for integration into laboratory and field EMC measurement chains.
IEEE 299
106 kHzFrequency coverage
106 kHz ±1%Receive frequency
±2 dBTest accuracy
PRODUCT CAPABILITY
Designed around the measurement.
Designed for shielding effectiveness applications
Operating coverage: 106 kHz
Supports integration into complete EMC measurement and test chains
Technical configuration is matched to the applicable method, interfaces and required accessories
KEY SPECIFICATIONS
At a glance.
Key published specifications for initial equipment selection. Final configuration, accessories and calibration scope are confirmed in the datasheet and quotation.
Receive frequency106 kHz ±1%
Test accuracy±2 dB
Attenuation range0 / 20 / 40 / 60 dB
Power supply220 V，50 Hz
Need the complete technical data?Download the English datasheet.
Building a complete test chain?Share the standard, level and test object.
Contact ZHINAN CONFIGURATION CHECKLIST
Make the quotation technically complete.
These are the points our application team will confirm before finalizing the model, accessories and calibration scope.
System interfaces
Identify the source, receiver, amplifier, cables, adapters and control requirements.
Documentation
Confirm the required datasheet, calibration scope, report language and acceptance evidence.
