CONDUCTED IMMUNITYZN23203
Electromagnetic Injection Clamp
An electromagnetic injection clamp for coupling RF disturbance onto cables in conducted-immunity testing.
IEC 61000-4-6
150 kHz–230 MHzFrequency range
EM clampCoupling method
50 ΩSystem interface
PRODUCT CAPABILITY
Designed around the measurement.
Non-contact electromagnetic coupling to the cable under test
Designed for repeatable conducted-immunity injection
Works with calibrated signal-generation and power-monitoring chains
Suitable when a direct CDN connection is not practical
KEY SPECIFICATIONS
At a glance.
Key published specifications for initial equipment selection. Final configuration, accessories and calibration scope are confirmed in the datasheet and quotation.
Frequency range150 kHz–230 MHz
Device typeElectromagnetic injection clamp
Nominal impedance50 Ω
Primary useRF disturbance injection
Need the complete technical data?Download the English datasheet.
Building a complete test chain?Share the standard, level and test object.
Contact ZHINAN CONFIGURATION CHECKLIST
Make the quotation technically complete.
These are the points our application team will confirm before finalizing the model, accessories and calibration scope.
System interfaces
Identify the source, receiver, amplifier, cables, adapters and control requirements.
Documentation
Confirm the required datasheet, calibration scope, report language and acceptance evidence.
PRODUCT QUESTIONS
What engineers ask before selection.
A concise starting point for evaluating ZN23203. The final model, accessories and calibration scope are confirmed against the complete test requirement.
What is the ZN23203 used for?
ZN23203 is designed for Conducted immunity, Cable testing, IEC 61000-4-6. Its published frequency coverage is 150 kHz–230 MHz.
What frequency range does the ZN23203 cover?
The published frequency coverage is 150 kHz–230 MHz. Final usable coverage depends on the complete measurement chain, interfaces, accessories and the applicable test method.
Which standards are associated with the ZN23203?
This product is associated with IEC 61000-4-6 on the ZHINAN product page. The exact edition, test setup and applicability should be confirmed for the customer project.
What information is needed to configure or quote the ZN23203?
Please provide the applicable standard, required frequency range and level, test object, existing equipment interfaces, accessories and calibration or documentation requirements.
RELATED EQUIPMENT
Browse this product family
