RE102 RECEIVE ANTENNASZN30703

Ka-Band Pyramidal Horn Receive Antenna

A Ka-band receiving antenna covering 26.5-40 GHz, for the high-frequency extension of an RE102 measurement system.

MIL-STD-461H

Request a quote Download datasheet

ZN30703 Ka-Band Pyramidal Horn Receive Antenna

26.5 GHz–40 GHzFrequency coverage

26.5 GHz–40 GHzFrequency range

50 Ω, K-typeConnector

PRODUCT CAPABILITY

Designed around the measurement.

Frequency range: 26.5 GHz–40 GHz

Connector: 50 Ω, K-type

Maximum power handling: 50 W

Weight: Approx. 0.4 kg

KEY SPECIFICATIONS

At a glance.

Key published specifications for initial equipment selection. Final configuration, accessories and calibration scope are confirmed in the datasheet and quotation.

Frequency range26.5 GHz–40 GHz

Connector50 Ω, K-type

Maximum power handling50 W

WeightApprox. 0.4 kg

Need the complete technical data?Download the English datasheet.

Building a complete test chain?Share the standard, level and test object.

Contact ZHINAN

CONFIGURATION CHECKLIST

Make the quotation technically complete.

These are the points our application team will confirm before finalizing the model, accessories and calibration scope.

Measurement role

Confirm receive or transmit use, polarization, field level and working distance.

Mechanical setup

Plan the mast or tripod, adapters, cable routing and required orientation.

Calibration package

Confirm antenna-factor, gain or VSWR data and the required calibration scope.

PRODUCT QUESTIONS

What engineers ask before selection.

A concise starting point for evaluating ZN30703. The final model, accessories and calibration scope are confirmed against the complete test requirement.

What is the ZN30703 used for?

ZN30703 is designed for RE102 testing, Radiated emissions, Full-band receive systems. Its published frequency coverage is 26.5 GHz–40 GHz.

What frequency range does the ZN30703 cover?

The published frequency coverage is 26.5 GHz–40 GHz. Final usable coverage depends on the complete measurement chain, interfaces, accessories and the applicable test method.

Which standards are associated with the ZN30703?

This product is associated with MIL-STD-461H on the ZHINAN product page. The exact edition, test setup and applicability should be confirmed for the customer project.

What information is needed to configure or quote the ZN30703?

Please provide the applicable standard, required frequency range and level, test object, existing equipment interfaces, accessories and calibration or documentation requirements.
